Capacity

100   Ah

150   Ah

200   Ah

  Rated Voltage

51.2   V

  Energy Storage

5.12   kWh

7.68   kWh

10.24   kWh

  Working Voltage

40 –   58.4 V

  Battery Type

LiFePO4

  Discharge Depth

>   80%

  Recommended Charging Current

50 A

80 A

100 A

  Max. Charging Current

100 A

150 A

200 A

  Max. Discharging Current

100 A

150 A

200 A

  Cycle Life Span

  > 2000 times @ 1C discharge

  > 5000 times @ 0.4C discharge

  Communication Mode

CAN/RS232/RS485

  BMS Protection

  Over Charge Protection

  Over Discharge Protection

  Over Current Protection

  Max. Number of Parallel Connection

16

  IP Grade

IP40

  Cooling Method

Nature   Cooling

  Operating Temperature

-20℃ to 70℃

  Recommended Working Temp.

10℃ to 45℃

  Max. Working Altitude

4000   m

  Net Weight

40 kg

60 kg

80 kg

  Dimensions

44x41x23   cm

44x41x23   cm

65x41x23   cm
